Hikvision DS-1LN6-UU 305 m Solid-Copper CAT6 UTP Cable

Hikvision DS-1LN6-UU 305 m Solid-Copper CAT6 UTP Cable

The Hikvision DS-1LN6-UU is a high-performance Category 6 network cable designed for structured cabling and premises distribution systems. With solid bare copper conductors (99.95%), it delivers reliable data transmission and power (PoE) over long distances.

Its core diameter of 0.565 mm (23 AWG) helps maintain stable impedance, while HDPE insulation ensures signal integrity. The outer sheath is made of PVC (CM-rated) in orange color (RAL 2003), giving both flexibility and fire resistance.

The DS-1LN6-UU offers excellent electrical performance:

• Impedance: 100 Ω ± 15 Ω over 1–250 MHz

• Delay skew: ≤ 45 ns / 100m

• DC resistance: max 9.38 Ω per 100 m

• Conductor resistance unbalance: ≤ 5%

It comes on a 305 m wooden tray, making it ideal for large installations. The cable has a rip cord for easier stripping and no drain wire, which helps maintain solid construction.

Built for durability, the cable passes aging tests (100°C × 24 h) with strong tensile strength and good elongation.

Key Features:

• 305 m CAT6 U/UTP cable

• 99.95% solid bare copper conductors

• 23 AWG (0.565 mm) core diameter

• HDPE insulation

• PVC outer sheath (CM-rated, flame resistant)

• Fluke-tested performance

• Long PoE transmission distance

• Rip-cord for easy installation
