Hikvision DS-1LN6UU/CCA 305 m Cat 6 UTP Cable (Copper-Clad Aluminum)
KSh 8,000.00KSh 10,000.00 (-20%)
Hikvision DS-1LN6UU/CCA 305 m Cat 6 UTP Cable (Copper-Clad Aluminum)
The Hikvision DS-1LN6UU/CCA is a 305 m Cat-6 U/UTP network cable with 23 AWG copper-clad aluminum (CCA) conductors, a PVC sheath, a CPR-Eca fire rating, Fluke-tested 90 m channel performance, ANSI/TIA-568.2-D compliance, and RoHS 2.0 certification.
| Specification | Detail |
|---|---|
| Model | DS-1LN6UU/CCA |
| Category | Cat 6 |
| Structure | U/UTP (4-pair) |
| Length | 305 ± 1.5 m |
| Conductor Material | Copper-Clad Aluminum (CCA) |
| Conductor Diameter | 0.57 ± 0.01 mm (23 AWG) |
| Insulation | HDPE, Ø 1.02 ± 0.05 mm |
| Jacket Material | PVC (Grey) |
| Outer Diameter | 6.4 ± 0.50 mm |
| Rip Cord | Yes |
| Separator | Yes |
| Fire Rating | CPR Eca |
| Standards | ANSI/TIA-568.2-D, RoHS 2.0 |
| Performance Test | Fluke 90-m channel test passed |
Hikvision DS-1LN6UU/CCA 305 m Cat 6 UTP Cable (Copper-Clad Aluminum)
The Hikvision DS-1LN6UU/CCA is a cost-effective Cat-6 U/UTP (unshielded twisted pair) cable built for structured indoor networking and data applications.
With copper-clad aluminum (CCA) conductors of 0.57 mm (23 AWG), it strikes a balance between conductivity and affordability. Its HDPE insulation preserves signal integrity over long runs.
The cable’s PVC outer jacket is engineered for durability, offering high tensile and compressive strength to reduce damage during installation. It includes both a rip cord and a separator for easier termination.
Performance-wise, it has passed a Fluke 90-meter channel test, proving its reliability for real-world Ethernet setups. The cable also carries a CE-CPR Eca fire rating, making it safer in the event of a fire. Additionally, it is RoHS 2.0-compliant, ensuring environmentally sound materials.
Key Features:
-
Cat-6 U/UTP network cable
-
305 m pull-box length
-
Copper-Clad Aluminum (CCA) conductors (23 AWG)
-
HDPE insulation
-
PVC jacket (grey) with strong mechanical strength
-
Rip cord and internal separator for easy installation
-
Fluke-tested 90-meter channel performance
-
CPR-Eca fire rating
-
RoHS 2.0 compliant
