Hikvision DS-7108HGHI-M1/T – 8-Channel Turbo HD Mini 1U DVR with H.265 Pro+
KSh 6,000.00KSh 7,000.00 (-14%)
Hikvision DS-7108HGHI-M1/T – 8-Channel Turbo HD Mini 1U DVR with H.265 Pro+
The Hikvision DS-7108HGHI-M1/T is an 8-channel Mini 1U DVR offering HDTVI/AHD/CVI/CVBS plus up to 10 IP channels, H.265 Pro+ compression, and Motion Detection 2.0 with human/vehicle classification. Ideal for efficient, hybrid analog/IP security systems with HDMI & VGA output and advanced recording.
| Feature | Details |
|---|---|
| Model / Part Number | Hikvision DS-7108HGHI-M1/T |
| Video Input | 8-channel analog BNC (HDTVI/AHD/CVI/CVBS) + IP video input up to 10 channels (up to 5 MP) |
| Max Encoding Resolution | 1080p Lite / 720p Lite at 15 fps (analog) |
| Video Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Storage Interface | 1 × SATA interface, up to 4 TB capacity per disk |
| Video Output | 1 × HDMI + 1 × VGA (simultaneous output) |
| Network Interface | 1 × RJ-45 10/100 Mbps Ethernet; total bandwidth ~72 Mbps |
| Motion Detection | Motion Detection 2.0 with human & vehicle classification |
| Power Supply/Consumption | 12 V DC, 1.5 A; ≤ 10 W (without HDD) |
| Operating Temperature | -10°C to 55 °C (14 °F to 131 °F) |
| Dimensions (W × D × H) | 200 × 200 × 48 mm (≈ 7.9″ × 7.9″ × 1.9″) |
| Weight | ≤ 1 kg (without HDD) |
| Warranty | Region-dependent limited hardware warranty |
Hikvision DS-7108HGHI-M1/T – 8-Channel Turbo HD Mini 1U DVR with H.265 Pro+
The Hikvision DS-7108HGHI-M1/T combines analog and IP recording flexibility in a compact 1U form-factor. With support for 8 analog channels plus up to 2 native IP channels (hybrid up to 10 channels), it’s an excellent choice for small offices, stores or home systems upgrading in stages.
Featuring deep-learning based Motion Detection 2.0 for human and vehicle classification across all analog channels, the DS-7108HGHI-M1/T minimizes false alarms and speeds up search of relevant events.
It supports HDTVI/AHD/CVI/CVBS inputs, 1080p Lite encoding, H.265 Pro+/H.265/H.264+ compression and simultaneous HDMI & VGA output—offering high flexibility in display and storage.
Key Features
-
8-channel analog input (HDTVI/AHD/CVI/CVBS) plus up to 10 total channels with IP input support.
-
H.265 Pro+ / H.265 / H.264+ / H.264 video compression for reduced storage and bandwidth.
-
Motion Detection 2.0 with human/vehicle classification for accurate alerts.
-
Simultaneous HDMI and VGA outputs for display flexibility.
-
1 × SATA interface (supports up to 4 TB HDD) for recording and playback.
-
Compact 200 × 200 × 48 mm 1U form-factor, ideal for space-constrained installations.
