Hikvision DS-7232HQHI-M2/XT – 32-Channel AcuSense 1U DVR with H.265
KSh 40,100.00KSh 45,000.00 (-11%)
Hikvision DS-7232HQHI-M2/XT – 32-Channel AcuSense 1U DVR with H.265
The Hikvision DS-7232HQHI-M2/XT is a 32-channel hybrid DVR supporting up to 40 IP camera inputs, advanced AcuSense AI analytics (human/vehicle & 4-ch facial recognition), and H.265 Pro+ compression—built for enterprise-level surveillance in high-demand environments.
| Feature | Details |
|---|---|
| Model / Part Number | Hikvision DS-7232HQHI-M2/XT |
| Video Input | 32-ch analog BNC (HDTVI/AHD/CVI/CVBS) + up to 40 IP camera channels (each up to 6 MP) |
| Maximum Encoding Resolution | Up to 3K/5 MP lite for analog; up to 6 MP for IP cameras |
| Video Compression | H.265 Pro+ / H.265 / H.264+ / H.264 |
| Storage Interface | 2 × SATA HDD bays (supports up to ~12 TB each) |
| Video Output | 1 × HDMI (4K) + 1 × VGA (simultaneous) |
| Network Interface/Bandwidth | 1 × RJ-45 10/100/1000 Mbps; Total bandwidth ~256 Mbps; up to 128 remote connections |
| Smart Features | AcuSense: human/vehicle classification; perimeter protection (8 ch); facial recognition (4 ch) |
| Power Supply/Consumption | 12 V DC, 5 A; ≤ 60 W |
| Operating Temperature | -10°C to +55 °C |
| Dimensions (W × D × H) | 384 × 313 × 52 mm (~15.1″ × 12.3″ × 2.0″) |
| Weight | ≤ 2.1 kg (~4.6 lb) |
| Warranty | Region-dependent limited hardware warranty |
Hikvision DS-7232HQHI-M2/XT – 32-Channel AcuSense 1U DVR with H.265
The Hikvision DS-7232HQHI-M2/XT is a high-performance 1U form-factor DVR designed for demanding surveillance systems that require a large channel count and advanced analytics. It supports 32 analog channels plus hybrid input up to 40 IP channels (up to 6 MP each) via HDTVI/AHD/CVI/CVBS/IP.
It features AcuSense deep-learning analytics, including human/vehicle classification across analog channels, perimeter protection (up to 8 ch), and facial recognition on up to 4 channels.
With efficient H.265 Pro+ compression, dual SATA HDD interfaces (up to ~12 TB each), 4K HDMI and VGA simultaneous output, and a compact rack-mount design (384 × 313 × 52 mm), this DVR provides enterprise-grade capabilities at competitive value.
Key Features
-
Hybrid support: 32 analog channels + up to 40 IP camera inputs
-
Five-signal adaptive input: HDTVI / AHD / CVI / CVBS / IP.
-
AcuSense intelligence: human/vehicle detection, perimeter protection, up to 4-channel facial recognition
-
Compression: H.265 Pro+ / H.265 / H.264+ / H.264
-
Decoding capability: up to 24 × 1080p at 30 fps
-
Two SATA bays supporting up to ~12 TB each
-
HDMI (4K) + VGA simultaneous output
-
Rack-mount 1U design, power consumption ≤ 60 W
