Hikvision DS-QAE0120G1R 20 W Analog Cabinet Speaker

Hikvision DS-QAE0120G1R 20 W Analog Cabinet Speaker

The Hikvision DS-QAE0120G1R is a durable and flexible analog cabinet speaker designed for high-quality sound in public address (PA) systems. Built with a 5.25″ driver, this speaker delivers clear audio for voice announcements and background music across commercial or institutional spaces.

It features selectable power taps—5 W, 10 W, 15 W, or 20 W—compatible with both 70 V and 100 V lines, giving you versatility in configuration and deployment.
With 90 dB ± 3 dB sensitivity (1 m / 1 W) and a maximum sound pressure level of 103 dB, the speaker ensures audio clarity and volume when paired with a compatible PA amplifier.
Its frequency response ranges from 130 Hz to 17.5 kHz, providing a full-range audio experience.

The speaker is designed for all-direction coverage and features a robust ABS body and metal mounting bracket. It supports both horizontal and vertical installation via a U-shaped bracket for flexible deployment.
It also offers a wide input interface: 70 V / 100 V constant-voltage lines or 8 Ω fixed resistance.
Built to resist harsh environments, it operates effectively across -30°C to +60°C, with less than 90% relative humidity (non-condensing).

Key Features:

• 20 W analog cabinet speaker, selectable power taps (5 / 10 / 15 / 20 W) at 70 V or 100 V

• High sensitivity (90 dB ±3) and high output (103 dB max)

• Full-frequency response: 130 Hz–17.5 kHz

• 5.25″ speaker driver for balanced audio output

• Supports constant-voltage (70 V / 100 V) or 8 Ω systems

• Durable ABS chassis + metal bracket for horizontal or vertical mounting

• Wide operating temperature range: –30 °C to +60 °C
