Inwin Modfree Deluxe Full Tower Black Gaming Case
|
Dimensions
|
|
|
Length / Depth
|
511.6 mm
|
|
Width
|
261.8 mm
|
|
Height
|
631 mm
|
|
Weight
|
14 kg
|
|
Case
|
|
|
Case Type
|
Full Tower
|
|
Motherboard Support
|
|
|
Compatible Motherboard Formats
|
ATX, E-ATX, Micro-ATX, Mini-ITX
|
|
Max. Motherboard Format
|
E-ATX
|
|
Internal Dimensions
|
|
|
Max. CPU Cooler Height
|
200 mm
|
|
Max. GPU Length
|
369 mm
|
|
Max. PSU Length / Depth
|
390 mm
|
|
Power Supply
|
|
|
PSU included
|
No
|
|
PSU Format
|
ATX
|
|
Fan Support
|
|
|
120 mm fans
|
7
|
|
160 mm fans
|
7
|
|
Radiator Support
|
|
|
Max. Radiator Compatibility
|
2x Triple (420 mm)
|
|
Drive Bays
|
|
|
2.5 / 3.5 inch internal drive bay (combined)
|
1
|
|
2.5 inch internal drive bay
|
2
|
Inwin Modfree Deluxe Full Tower Black Gaming Case
ModFree utilizes a fully systematic architectural structure that consists of interchangeable toolless modules. PC enthusiasts can freely transform their new PC internally and externally to accommodate their needs and preferences. Two preconfigured sets are starting points for users. The Base Edition consists of two modules, while the Deluxe Edition possesses four modules providing additional options for your PC setup. Users can add expansion modules to enhance their builds at any time. ModFree has three different modules to customize a system to meet your requirements. Investing in this ecosystem will prove cost-effective since upgrades are just a module away, which also reduces environmental impact with less hardware waste. The toolless interlocking clip design allows users to switch modules in an instant. Building hardware in each module is hassle-free, and assembling the modules together requires just one step. Unlike conventional cases, inverted layouts benefit users wanting to showcase their hardware from the left side of the desk, where they may have more space. Equipped with a 2-in-1 audio/microphone jack utilizing the international CTIA standard, which is compatible with most gaming peripherals. Quick removable filter and feet design allow users to not only clean quickly, but install on different modules easily, too. Modular design, multifaceted system layout, flexible orientation deployment, endless swappable modifications!
| Model | IW-CS-MFDELU-BLK |
| Colour | Black |
| Lighting | ARGB |
| Materials | SECC, Tempered Glass, ABS |
| Dimensions | 511mm x 262mm x 612mm |
| Form Factor | Full Tower |
| Motherboard Support | E-ATX, ATX, Micro ATX, Mini ITX |
| Front I/O | 2 x USB 3.2 Gen 1 1 x USB 3.2 Gen 2×2 Type-C 1 x Headphone Out / Mic In 1 x Power Button |
| Side Panel | Tempered Glass |
| Drive Bays | 5.25″: 0 3.5″/2.5″ Combo: 1 x 3.5″ / 2 x 2.5″ 3.5″: 0 2.5″: 2 |
| Expansion Slots | 9 |
| Fan Support | Front: 3 x 120mm / 3 x 140mm Top: 3 x 120mm / 3 x 140mm Back: 1 x 120mm / 1 x 140mm Bottom: None Side: None |
| Radiator Support | Front: 420mm / 360mm / 280mm / 240mm / 140mm / 120mm Top: 420mm / 360mm / 280mm / 240mm / 120mm Back: None Bottom: None Side: None |
| Clearances | CPU Cooler: 200mm GPU Length: 369mm (440mm with Mod-III and pre-installed fans) PSU Length: 390mm (240mm with hard drive tray installed) |
| Weight | Not Specified |
| Warranty | 2 Years |
