HIKVISION Products

Hikvision DS-3E0524R-O 24-Port Gigabit Rack-Mount Ethernet Switch

The Hikvision DS-3E0524R-O is a 24-port 10/100/1000 Mbps unmanaged Gigabit switch with fan-free metal housing, 48 Gbps switching capacity, 6 kV surge protection, rack-mountable design, and plug-and-play setup—ideal for offices, CCTV systems, and network-dense environments.

Specification	Detail
Model	DS-3E0524R-O
Ports	24 × 10/100/1000 Mbps RJ45
Switching Capacity	48 Gbps
Packet Forwarding Rate	35.71 Mbps
MAC Address Table	8,000 entries (8 K)
Internal Cache	4.1 Mbits
Housing	Metal, fan-free
Installation Mode	Rack-mount (mounting ears included)
Net Weight	0.9 kg
Dimensions (W × H × D)	327.00 mm × 44.00 mm × 118.00 mm
Power Input	100-240 VAC, 50/60 Hz
Max Power Consumption	18 W
Idle Power Consumption	3.8 W
Surge Protection	6 kV
Operating Temperature	0°C – 40 °C
Storage Temperature	–40 °C – 85 °C
Operating Humidity	5% – 95% (non-condensing)

KSh 9,800.00~~KSh 11,000.00~~

Hikvision DS-3E0524R-O 24-Port Gigabit Rack-Mount Ethernet Switch

KSh 9,800.00~~KSh 11,000.00~~

Hikvision DS-3E0526P-E 24-Port Gigabit PoE Unmanaged Switch

The Hikvision DS-3E0526P-E is a 24-port Gigabit RJ45 unmanaged PoE switch with an uplink RJ45 port and SFP fiber port, offering up to 30 W per port and 370 W total PoE power budget, 52 Gbps switching capacity, and 6 kV surge protection—ideal for powering IP cameras, access points, and large surveillance or network systems.

Specification	Detail
Model	DS-3E0526P-E
Ports	24 × Gigabit PoE RJ45 ports, 1 × Gigabit RJ45 uplink port, 1 × Gigabit SFP fiber uplink port
PoE Standard	IEEE 802.3af, IEEE 802.3at
Max PoE Power per Port	30 W
Total PoE Power Budget	370 W
MAC Address Table	8,000 entries (8 K)
Switching Capacity	52 Gbps
Packet Forwarding Rate	38.69 Mpps
Internal Cache / Buffer	4.1 Mbits
Housing	Metal chassis (rack-mountable / desk-mountable)
Surge Protection (PoE ports)	6 kV
Power Supply	100–240 VAC, 50/60 Hz
Max Power Consumption	400 W
Dimensions (W × H × D)	440.0 mm × 44.0 mm × 220.8 mm
Net Weight	2.88 kg
Operating Temperature	–10 °C to 55 °C
Storage Temperature	–40 °C to 85 °C
Operating Humidity	5% – 95% (non-condensing)
Installation Mode	Rack-mount (mounting ears included) or Desk-mount

KSh 31,750.00~~KSh 35,000.00~~

Hikvision DS-3E0526P-E 24-Port Gigabit PoE Unmanaged Switch

KSh 31,750.00~~KSh 35,000.00~~

Hikvision DS-3E1552P-SI 48-Port Gigabit Smart PoE Switch

The Hikvision DS-3E1552P-SI Smart PoE Switch features 48 Gigabit PoE ports, 4 uplink ports (2 × RJ45 + 2 × SFP), a 470 W PoE budget, VLAN, QoS, and advanced L2 management for enterprise networks, CCTV, and surveillance infrastructure.

Specification	Detail
Model	Hikvision DS-3E1552P-SI
Ports	48× Gigabit PoE, 2× Gigabit RJ45, 2× Gigabit SFP
PoE Standard	IEEE 802.3af/at
Max PoE Power Budget	470 W
Max PoE per Port	30 W
Switching Capacity	104 Gbps
Forwarding Rate	77.38 Mpps
L2 Features	VLAN, QoS, STP/RSTP, ERPS, Link Aggregation
Security	ACL, Port Isolation, Storm Control, DHCP Snooping
Management	Web, SNMP, CLI, PoE Watchdog
Surge Protection	6 kV

KSh 76,000.00~~KSh 80,000.00~~

Hikvision DS-3E1552P-SI 48-Port Gigabit Smart PoE Switch

KSh 76,000.00~~KSh 80,000.00~~

Hikvision DS-3WAP521-SI Wi-Fi 5 1200 Mbps In-Wall Access Point

The Hikvision DS-3WAP521-SI is a dual-band Wi-Fi 5 (802.11ac Wave 2) in-wall access point delivering combined speeds up to 1200 Mbps, built-in PoE support, dual Gigabit LAN ports, auto RF optimization, and intelligent fast roaming — ideal for offices, hotels, and high-density indoor environments.

Specification	Detail
Model	Hikvision DS-3WAP521-SI
Wireless Standard	Wi-Fi 5 (802.11ac Wave 2)
Frequency Bands	2.4 GHz & 5 GHz
Max Wireless Speed	1200 Mbps (300 + 867 Mbps)
Antenna	Built-in omnidirectional (2 × 2.4 GHz, 2 × 5 GHz)
Spatial Streams	2×2 MU-MIMO on both bands
Concurrent Users	50+ recommended, up to 128 max
LAN Ports	2 × Gigabit RJ45 (1 PoE input)
Power	PoE (IEEE 802.3af/at)
SSIDs	Up to 8
Security	WPA-PSK, WPA2-PSK, VLAN/SSID Binding
Installation	In-wall (86 mm junction box)
Dimensions	86 × 86 × 35 mm
Power Consumption	Max 8 W

KSh 7,475.00~~KSh 8,500.00~~

Hikvision DS-3WAP521-SI Wi-Fi 5 1200 Mbps In-Wall Access Point

KSh 7,475.00~~KSh 8,500.00~~

Hikvision DS-3WAP522-SI Wi-Fi 5 1200 Mbps Ceiling Access Point

The Hikvision DS-3WAP522-SI Wi-Fi 5 1200 Mbps Ceiling Access Point delivers dual-band wireless connectivity (2.4 GHz + 5 GHz), MU-MIMO, auto RF optimization, PoE support, and centralized management — ideal for offices, schools, and public spaces requiring reliable high-density Wi-Fi coverage.

Specification	Detail
Model	Hikvision DS-3WAP522-SI
Wi-Fi Standard	IEEE 802.11a/b/g/n/ac (Wi-Fi 5)
Frequency Bands	2.4 GHz & 5 GHz
Maximum Wireless Speed	Up to 1200 Mbps (300 Mbps + 867 Mbps)
Antenna	Built-in Omnidirectional Antennas
Number of Clients Supported	Up to 256 (80 recommended)
Management	Centralized AC Management / Web UI
Security	WPA/WPA2/WPA3, MAC Filtering, SSID/VLAN Binding
Interface	1 × Gigabit RJ45 Uplink Port
Power Supply	IEEE 802.3af/at PoE, 12 VDC 1.5 A
Installation	Ceiling Mount
RF Optimization	Auto RF Optimization
Roaming	Intelligent Fast Roaming

KSh 7,840.00~~KSh 9,000.00~~

Hikvision DS-3WAP522-SI Wi-Fi 5 1200 Mbps Ceiling Access Point

KSh 7,840.00~~KSh 9,000.00~~

Hikvision DS-3WAP621E-SI Wi-Fi 6 3000 Mbps In-Wall Access Point

The Hikvision DS-3WAP621E-SI is a high-performance Wi-Fi 6 (802.11ax) in-wall access point with combined speeds up to ~3000 Mbps, dual Gigabit Ethernet (one PoE), MU-MIMO, auto RF optimization, and support for 70+ concurrent clients — ideal for offices, hotels, and dense indoor wireless networks

Specification	Detail
Model	Hikvision DS-3WAP621E-SI
Wireless Standard	Wi-Fi 6 (802.11ax)
Frequency Bands	2.4 GHz & 5 GHz
Max Wi-Fi Speed	2.4 GHz: 575 Mbps • 5 GHz: 2400 Mbps (≈2975 Mbps)
Spatial Streams	2×2 MU-MIMO (both bands)
Max Clients Supported	256
Recommended Clients	70
LAN Ports	1 × Gigabit RJ45 (PoE input), 1 × Gigabit RJ45 LAN
Power Supply	PoE (IEEE 802.3af/at)
Max SSIDs	8
Installation	In-wall mount (86 mm junction box)
Antenna	Built-in omnidirectional antennas
Antenna Gain	2.4 GHz: 3 dBi • 5 GHz: 5 dBi
Transmit Power	18 dBm
Power Consumption	Max 13 W
Dimensions	86 × 86 × 44.4 mm
Operating Temp.	0 °C to 40 °C

KSh 11,500.00~~KSh 13,000.00~~

Hikvision DS-3WAP621E-SI Wi-Fi 6 3000 Mbps In-Wall Access Point

KSh 11,500.00~~KSh 13,000.00~~

Hikvision DS-3WAP622E-SI Wi-Fi 6 3000 Mbps Ceiling Access Point

The Hikvision DS-3WAP622E-SI Wi-Fi 6 3000 Mbps ceiling access point delivers ultra-fast dual-band wireless, MU-MIMO, auto RF optimization, intelligent fast roaming, and PoE support — ideal for offices, schools, hotels, and high-density indoor environments.

Specification	Detail
Model	Hikvision DS-3WAP622E-SI
Wireless Standard	Wi-Fi 6 (IEEE 802.11ax)
Frequency Bands	2.4 GHz & 5 GHz
Max Wireless Speed	2.4 GHz: 575 Mbps • 5 GHz: 2400 Mbps (total ~2975 Mbps)
Spatial Streams	2×2 MU-MIMO on both bands
Max Clients Supported	256
Recommended Clients	100+
Max SSIDs	8
Interface	1× 2.5 Gigabit RJ45 uplink
Power Supply	IEEE 802.3af/at PoE • 12 VDC 1.5 A
Antenna	Built-in omnidirectional (2.4 GHz: 3 dBi; 5 GHz: 4 dBi)
Channel Width	2.4 GHz: Auto/20/40 MHz • 5 GHz: Auto/20/40/80/160 MHz
Power Consumption	Max. 13.5 W
Installation	Desk, Wall, or Ceiling Mount
Weight & Dimensions	0.37 kg • 220×220×39 mm

KSh 15,000.00~~KSh 17,500.00~~

Hikvision DS-3WAP622E-SI Wi-Fi 6 3000 Mbps Ceiling Access Point

KSh 15,000.00~~KSh 17,500.00~~

Hikvision DS-3WAP622G-SI Wi-Fi 6 1800 Mbps Ceiling Access Point

The Hikvision DS-3WAP622G-SI Wi-Fi 6 ceiling access point delivers high-speed dual-band 802.11ax connectivity up to 1800 Mbps with MU-MIMO, PoE support, auto RF optimisation, intelligent fast roaming, and support for 100+ concurrent users — ideal for offices, schools, shops and high-density indoor coverage.

Specification	Detail
Model	Hikvision DS-3WAP622G-SI
Wireless Standard	Wi-Fi 6 (802.11ax)
Frequency Bands	2.4 GHz & 5 GHz
Max Wireless Speed	Up to 1800 Mbps (574 + 1201 Mbps)
Antennas	Built-in omnidirectional (2.4 GHz: 2, 5 GHz: 2)
Spatial Streams	2×2 MU-MIMO
Supported Clients	Up to 256 (100+ recommended)
SSIDs	Up to 8
Uplink Port	1 × Gigabit RJ45
Power Supply	PoE (802.3af/at) or 12 VDC
Mounting	Ceiling / Wall / Desk
Dimensions	220 × 220 × 35 mm
Power Consumption	Max 11.35 W
Operating Temp.	0 °C to 40 °C

KSh 11,400.00~~KSh 13,000.00~~

Hikvision DS-3WAP622G-SI Wi-Fi 6 1800 Mbps Ceiling Access Point

KSh 11,400.00~~KSh 13,000.00~~

Hikvision DS-3WAP623E-SI Outdoor Wi-Fi 6 3000 Mbps Access Point

The Hikvision DS-3WAP623E-SI Outdoor Wi-Fi 6 Access Point delivers ultra-fast 3000 Mbps dual-band wireless, rugged IP67/IP68 weatherproofing, PoE support, intelligent fast roaming, and broad client support — ideal for outdoor wireless coverage in campuses, estates, and commercial spaces.

Specification	Detail
Model	Hikvision DS-3WAP623E-SI
Wireless Standard	Wi-Fi 6 (IEEE 802.11ax)
Frequency Bands	2.4 GHz & 5 GHz
Max Wireless Speed	2.4 GHz: 575 Mbps \| 5 GHz: 2400 Mbps (≈3000 Mbps total)
Spatial Streams	2×2 MU-MIMO (both bands)
Max Clients Supported	256
Recommended Clients	100+
SSIDs	Up to 8
Uplink Port	1 × Gigabit RJ45 (PoE input)
Power Supply	PoE (IEEE 802.3af/at), 48 VDC 0.3 A
Weatherproof Rating	IP67 / IP68
Installation Modes	Wall-mount, Pole-mount
Working Temp.	30 °C to 55 °C
Dimensions (W × H × D)	102 × 110 × 250 mm
Weight	Approx. 1.07 kg
Auto RF & Roaming	Yes

KSh 21,875.00~~KSh 23,000.00~~

Hikvision DS-3WAP623E-SI Outdoor Wi-Fi 6 3000 Mbps Access Point

KSh 21,875.00~~KSh 23,000.00~~

Hikvision DS-3WF0BC-2NT(B) 2.4 GHz 300 Mbps Elevator Wireless Bridge

The Hikvision DS-3WF0BC-2NT(B) Elevator Wireless Bridge delivers a 2.4 GHz 300 Mbps link with up to 200 m range, compact PoE-ready design, and visualized network management—ideal for CCTV, intercom, and connectivity in elevator shafts and challenging vertical environments.

Feature	Specification
Model	Hikvision DS-3WF0BC-2NT(B)
Wireless Standard	IEEE 802.11b/g/n (2×2 MIMO)
Frequency Band	2.4 GHz (2400–2483.5 MHz)
Max Wireless Speed	300 Mbps
Range	Up to 200 m (open line-of-sight)
Antenna	Built-in 7 dBi 2×2 MIMO
Ethernet Ports	2× 10/100 Mbps RJ45
Power Supply	12–24 V Passive PoE or adapter
Security	WPA2-PSK wireless encryption
Management	Web, iVMS-4200, HCP
Operating Temp.	30 °C to 70 °C
Application	Elevator shafts, CCTV links, intercom data bridges

KSh 6,240.00~~KSh 7,500.00~~

Hikvision DS-3WF0BC-2NT(B) 2.4 GHz 300 Mbps Elevator Wireless Bridge

KSh 6,240.00~~KSh 7,500.00~~

Hikvision DS-3WF3000-EI/5AC-P 5 GHz 867 Mbps 3 km Wireless Bridge Kit

The Hikvision DS-3WF3000-EI/5AC-P Wireless Bridge Kit delivers up to 867 Mbps data throughput over 5 GHz with long-range communication up to 3 km, making it ideal for backbone wireless links, CCTV connectivity, and outdoor site networking.

Feature	Specification
Model	Hikvision DS-3WF3000-EI/5AC-P
Wireless Standard	IEEE 802.11ac (5 GHz)
Max Wireless Speed	Up to 867 Mbps
Frequency Band	5 GHz
Range	Up to 3 km (line-of-sight)
Antenna	Integrated High-Gain Directional
Connectivity	Ethernet (PoE supported)
Deployment	Point-to-Point Link Kit
Environment	Outdoor (Weather-Resistant)
Recommended Use	CCTV Backhaul, Site-to-Site Networking

KSh 14,200.00~~KSh 16,000.00~~

Hikvision DS-3WF3000-EI/5AC-P 5 GHz 867 Mbps 3 km Wireless Bridge Kit

KSh 14,200.00~~KSh 16,000.00~~

Hikvision DS-3WG105G-SI Smart Managed Router

The Hikvision DS-3WG105G-SI smart managed router delivers robust all-in-one Gigabit routing with dual WAN, multi-WAN load balancing, advanced security, VPN support, behavior-based traffic management, and support for up to 100 users — ideal for small offices, surveillance networks, and business connectivity.

Specification	Detail
Model	Hikvision DS-3WG105G-SI
Product Type	Smart Managed Router
WAN Ports	2 × Gigabit (1 switchable)
LAN Ports	3 × Gigabit (2 switchable)
Forwarding Capacity	10 Gbps
Max Clients Supported	100 concurrent
Security Features	Firewall, DDoS, IP/MAC/URL filtering, ARP defense
VPN Support	IPsec, L2TP
Traffic Management	Behavior-based QoS
Management	Hik-Partner Pro, Web interface
Housing	Metal chassis
Power Input	12 V DC, ~12 W
Operating Temp.	0 °C to 45 °C
Dimensions	190 × 125.6 × 29 mm
Weight	0.5 kg

KSh 9,200.00~~KSh 11,000.00~~

Hikvision DS-3WG105G-SI Smart Managed Router

KSh 9,200.00~~KSh 11,000.00~~
